高频变压器包括 EE/ED/ER/EC/EF/EP/ETD/PQ/RM/UU/ET/UT...等类型。
FEATURES •HIGH FREQUENCY POWER TRANSFORMER •HIGH FREQUENCY SWITCHING TRANSFORMER •CURRENT SENSORS •WIDE VARIETY OF OTHER SIZES AND VALUES AVAILABLE
PART NO.
TERMINAL PINS
Dimensions in mm (inches)
A
B
C
D
E
F
EPC-10
8
5.5
10.2
11.5+/-0.5
2.0
10.9
EPC-13
10
6.8
17.2
20.2+/-0.2
3.0
14
EPC-19
9.5
22.5
25
3.5
20
EPC-25
11.5
27.6
29.6
3.8
