Lamination

(mm)

 Stack

  (mm)

Model No

 Volume

 (VA)

Distance Between Pins(mm)

Array Pitch(mm)±0.5mm

Overall Dimension

(mm)a*b*c±0.5mm

N*E

N*F

EI24

8

EI24-1-X

0.4-0.5

3*4.8

3*4.8

15

26*22*22

EI-28

11

EI28-1-X

0.5-1.0

2*7.0

3*5.0

20

29*28*26

12

EI28-2-X

1.0-1.5

4*4.9

4*4.9

20

29*28*26

12

EI28-2A-X

0.8-1.5

2*7.5

3*5.0

22

29*28*28.1

15

EI28-3-X

1.5-2.0

4*4.9

4*4.9

20

29*28*30

18

EI28-4-X

2.0-3.0

4*4.9

4*4.9

20

29*28*32

EI-30

10.5

EI30-1-X

1.0-1.5

4*5.0

4*5.0

20

31*26*20

15

EI30-2-X

2.0-2.5

4*5.0

4*5.0

20

31*26*25

18

EI30-3-X

2.5-3.0

4*5.0

4*5.0

20

31*26*28

22

EI30-4-X

3.5-4.0

4*5.0

4*5.0

20

31*26*31

EI-35

10

EI35-1-X

1.5-2.0

4*5.6

4*5.6

21.5

36*31*25.5

12

EI35-2-X

1.0-2.0

2*7.5

3*5.0

22.1

36*31*31

12

EI35-2A-X

1.0-2.0

2*7.5

5+4.8+5

21.8

36*31*31

13.5

EI35-3-X

2.0-2.5

3*6.3

3*6.6

29.9

36*31*32

14

EI35-4-X

1.0-2.0

4*5.0

4*5.0

23.4

36*31*32.5

14.5

EI35-5-X

2.0-3.0

3*6.0

4*4.5

21.1

36*31*35

15

EI35-6-X

3.0-4.0

4*5.6

4*5.6

21.7

36*31*32

15

EI35-6A-X

2.0-3.0

2*7.5

3*6.0

22

36*31*32

15

EI35-6B-X

3.0-4.0

4*5.0

4*5.0

21

36*31*32

18

EI35-7-X

4.0-5.0

4*4.7

4*4.7

22.5

36*31*38

18

EI35-7A-X

4.0-5.0

4*5.0

4*5.0

21.5

36*31*34

20

EI35-8-X

4.0-5.5

4*5.6

4*5.6

21.7

36*31*37

20

EI35-8A-X

5.0-5.5

4*5.0

4*5.0

23

36*31*37

EI-41

10

EI41-1-X

2.0-3.0

2*9.1

2*9.1

23.7

42*34*25

13

EI41-2-X

4.0-5.0

5*6.35

5.08+4*6.35

25

42*34*30

15

EI41-3-X

4.0-5.0

5*4.9

5*4.9

25

42*34*30

15.5

EI41-4-X

3.5-4.5

5.3+2*4.5+5.3

5.3+2*4.5+5.3

23

42*34*40

16

EI41-5-X

4.0-5.0

4*5.0

4*5.0

25

42*34*30
